Update Firmware HP 1910 Switches



So I was updating the firmware on a HP 1910 switch and though I would share a quick how to with everyone. Here it goes.







You can remotely download Boot ROM and system software images from a TFTP server at the CLI as

follows.

Step 1: Configure an IP address for the switch

<HP V1910 Switch>ipsetup ip-address 192.168.1.2 24

Step 2: Download the system software image file from the TFTP server.

<HP V1910 Switch>upgrade 192.168.1.1 update.bin runtime

The file flash:/ main.bin exists. Overwrite it? [Y/N]:y

Verifying server file...

Deleting the old file, please wait...

File will be transferred in binary mode

Downloading file from remote TFTP server, please wait.../

TFTP: 10262272 bytes received in 104 second(s)

File downloaded successfully.

The specified file will be used as the boot file at the next reboot.

Step 3: Download and load the Boot ROM file.

<HP V1910 Switch>upgrade 192.168.1.1 update.btm bootrom

File will be transferred in binary mode

Downloading file from remote TFTP server, please wait...|

TFTP: 259324 bytes received in 2 second(s)

File downloaded successfully.

BootRom file updating finished!

Step 4: Reboot the device to validate the new system software.

<HP V1910 Switch> reboot

Note that if flash memory is insufficient, load the Boot ROM image first and delete useless files to free up

Flash memory before you load the system software image.
